32Ah 3.2V lithium lifepo4 rechargeable battery cell prismatic cell power supply

Model：LF32
nominal capacity：32Ah（mah）
nominal voltage：3.2V（V）
charging current：2C（A）
charging voltage：3.65V
storage temperature：-20℃~45℃
operate temperature：-20℃~55℃
Weight：725±50（g）

Classification:

Products

Lithium Battery Cell（prismatic）

Online Message

▌Specifications

Model : LF32
Rated capacity : 32Ah (mah)
Standard voltage : 3.2V (V)
Charging current : 2C (A)
Rechargeable : Yes
Charging voltage: 3.65V
Storage temperature : - 20 ℃~45 ℃
Operating temperature : - 20 ℃~55 ℃
Net weight : 725 ± 50 (g)

NO	ITEM		PARAMETER	NOTE
1	nominal capacity		32Ah	(25+/2)℃,standard charge&discharge
2	nominal voltage		3.2V
3	inner resistance(1kHz)		≦1.5mΏ
4	standard charge and discharge	charge/discharge current	0.5C/0.5C	(25+/2)℃
		charge/discharge cut off voltage	3.65V/2.5V
5	max charge/discharge currency	continuous charge/discharge	1C/1C	N.A.
		pulse charge/discharge(30s)	1.2C/2C
6	Recommended window for SOC		10%-90%
7	charging working temperature		0℃-55℃
8	discharge working temperatue		-20℃-55℃
9	storage temperature	short period	-20℃-45℃
		long period	0℃-35℃
10	Storage humidity		<95%
11	monthly discharge rate		≦3%/m	(25+/2)℃,30%-50% SOC storage
12	SIZE	Width	148.2±0.5mm	N.A.
13		thickness（300kgf,30%-40%SOC)	26.7±0.5mm
14		total height（主体高）	91.5±0.5mm
15		body height（总高）	94.3±0.5mm
16		pole center distance	114.6±0.3mm
17	battery weight		725±50g
